EMMC5.1 64GB Domestically Independent And Controllable EMMC 128GB 256GB Self-Developed Controller Yangtze Memory Chips Supply Chain Security

50pcs
MOQ
Negotiable
Price
EMMC5.1 64GB Domestically Independent And Controllable EMMC 128GB 256GB Self-Developed Controller Yangtze Memory Chips Supply Chain Security
Features Gallery Product Description Request A Quote
Features
Specifications
Working Temperature: -20~85℃
Oem: Support
Storage Capacity: 64GB/128GB/256GB
Quality: Genuine Original
Compatibility: Tablet PC/ Set-top Box
Sequential Write Speed: Up To 240 MB/s
Custom: Support
Choice Of Flash: MLC / 3D TLC / QLC NAND
Operating Voltage: 2.7V - 3.6V
Highlight:

2.5 inch sata ssd 1tb

,

256gb 2.5 inch sata ssd

,

256gb 2.5 inch sata 3 ssd
Basic Infomation
Place of Origin: China
Brand Name: PG
Model Number: G28128TLCB/G2864GTLCB/G28256TLCB
Payment & Shipping Terms
Delivery Time: 10 to 15 days
Payment Terms: L/C,T/T
Supply Ability: 100K a month
Product Description
EMMC5.1 64GB Domestically Independent And Controllable EMMC
Advanced eMMC5.1 storage solutions featuring 64GB, 128GB, and 256GB capacities with self-developed controllers and Yangtze Memory chips, ensuring complete supply chain security and domestic independence.
CB EMMC5.1 Technical Specifications
Model G2864GTLCB G28128TLCB G28256TLCB
NAND Flash 3DTLC NAND 3DTLC NAND 3DTLC NAND
Capacity 64GB 128GB 256GB
CE 1 2 4
Read Speed up to 330MB/s up to 330MB/s up to 330MB/s
Write Speed up to 240MB/s up to 240MB/s up to 240MB/s
Operating Temperature -25℃~85℃ -25℃~85℃ -25℃~85℃
EP ≥3000 ≥3000 ≥3000
Packaging Specification BGA 153 BGA 153 BGA 153
Size 11.5mm×13mm×1.0mm 11.5mm×13mm×1.0mm 11.5mm×13mm×1.2mm
Understanding eMMC Technology
eMMC (Embedded MultiMediaCard) is a standardized embedded non-volatile storage solution developed by JEDEC (Joint Electron Device Engineering Council). Rather than being a single storage chip, eMMC represents a Chip-On-Board (COB) integrated module that combines NAND flash memory chips with MMC controllers on a single substrate, communicating with host processors through standardized interfaces.
The core value of eMMC technology lies in standardization and integration. JEDEC's unified interface specifications, communication protocols, and physical packaging ensure compatibility between eMMC modules from different manufacturers and host chips across various brands, significantly reducing R&D complexity and supply chain costs for end devices.
The integrated design of controller and flash memory substantially reduces storage module size, making eMMC ideal for embedded devices requiring compact form factors and low power consumption.
Application Distinctions
While eMMC, SD cards, and USB drives all utilize flash memory storage technology, their application scenarios differ significantly. SD cards serve as removable external storage, while eMMC functions as internal storage permanently soldered to device motherboards, designed for embedded systems demanding superior stability and integration.
Tag:

Embedded eMMC5.1

eMMC BGA153

Memory Chip IC eMMC
