Wholesales 3D TLC EMMC 64GB 128GB 256GB EMMC Chip For Motherboard Robot Phone POS Machine
Product Specification
Place of Origin:
Shenzhen, China
Brand Name:
PG
Model Number:
G2864TLCB/G28128TLCB/G28256TLCB/G2564LTCB/G25128LTCB/G25256LTCB
Minimum Order Quantity:
50pcs
Price:
Negotiable
Delivery Time:
10 to 15 days
Payment Terms:
L/C,T/T
Supply Ability:
100K a month
Product Summary
Wholesale 3D TLC eMMC Memory Chips High-quality eMMC memory chips available in multiple capacities with BGA-153 packaging. Our industrial-grade eMMC 5.1 solutions deliver exceptional performance and reliability for demanding applications. PG Libra Series eMMC 5.1 Specifications Model G2564GTLIA ...
Product Details
Highlight:
3D TLC EMMC
,256GB EMMC Chip
,EMMC Chip 64GB BGA153
Reliability Features:
Enhanced Data Reliability With Improved ECC And Wear Leveling
Condition:
New
Logo:
OEM
Choice Of Flash:
MLC / 3D TLC / QLC NAND
Interface:
MMC (MultiMediaCard) Interface
Dimensions:
11.5mm X 13mm X 1.0mm
Trim/Erase:
Supports Trim And Secure Erase Commands
Bus Speed:
HS400 (up To 400MB/s)
Quality:
100% Original
Warranty:
1 Year
Nand Flash:
TLC
Status:
Good Health
Boot Operation:
Supports Boot Partitions With Secure Boot Features
Operating Voltage:
2.7V - 3.6V
Write Speed:
240MB/s
Product Description
Wholesale 3D TLC eMMC Memory Chips
High-quality eMMC memory chips available in multiple capacities with BGA-153 packaging. Our industrial-grade eMMC 5.1 solutions deliver exceptional performance and reliability for demanding applications.
PG Libra Series eMMC 5.1 Specifications
| Model | G2564GTLIA | G25128TLIA | G25256TLIA | G25512TLIA |
|---|---|---|---|---|
| NAND Flash | 3DTLC NAND | 3DTLC NAND | 3DTLC NAND | 3DTLC NAND |
| Capacity | 64GB | 128GB | 256GB | 512GB |
| CE | 1 | 2 | 4 | 4 |
| Read Speed | up to 330MB/s | up to 330MB/s | up to 330MB/s | up to 330MB/s |
| Write Speed | up to 240MB/s | up to 240MB/s | up to 240MB/s | up to 240MB/s |
| Operating Temperature | -25℃~85℃ | -25℃~85℃ | -25℃~85℃ | -25℃~85℃ |
| EP | ≥7000 | ≥7000 | ≥7000 | ≥7000 |
| Packaging Specification | BGA 153 | BGA 153 | BGA 153 | BGA 153 |
| Size | 11.5mm*13mm*1.0mm | 11.5mm*13mm*1.0mm | 11.5mm*13mm*1.2mm | 11.5mm*13mm*1.2mm |
Typical Application Scenarios
- Vehicle-mounted electronics: vehicle-mounted central control, ADAS system, driving recorder
- Industrial equipment: PLC controller, industrial tablet, smart electric meter
- Security monitoring: high-definition camera, NVR storage device
- Medical equipment: portable diagnostic instrument, medical monitor
