High Speed 1TB TF SD Memory Card 16GB 32GB 64GB 128GB 256GB 512GB A1 A2 U1 U3

Negotiable
Price
High Speed 1TB TF SD Memory Card 16GB 32GB 64GB 128GB 256GB 512GB A1 A2 U1 U3
Features Gallery Product Description Request A Quote
Features
Specifications
Capacity: 256GB
Color: Customizable
Package: Customizable
Read Speed: 180MB/s
Write Speed: 135MB/s
File System: FAT32/exFAT
Highlight:

High Speed TF SD Memory Card

,

1TB SD Memory Card

,

256GB SD Memory Card

Basic Infomation
Place of Origin: China
Brand Name: PG
Model Number: S25256TLCA
Payment & Shipping Terms
Delivery Time: 10 to 15 days
Payment Terms: L/C, T/T
Supply Ability: 100K a month
Product Description
High Speed TF Card 1TB Sd Memory Card 16GB 32GB 64GB 128GB 256GB 512GB Memory Cards A1 A2 Ultra Class 10 U1 U3


Ultra High Definition
4K UHD ultra high definition playback with UHS-I and video speed level 30 (V30).

Low-power Consumption
Large capacity QLC supports low voltage and low power consumption, ensuring longer device usage time

High Speed Reading and Writing
AS advanced ECC error correction technology plus DDR104, A1 level program loading, UP 90MB/s Read, 50MB/s Write
SA advanced LDPC error correction technology plus DDR200, A2-level program loading, UP 180MB/s Read, 135MB/s Write

Commercial Applications
The capacity of this card ranges from 32GB to 1TB and can be used to store various business applications such as
e-learning, portable audio, IP cameras, dash cams, wearable smart devices, Android devices, game consoles, etc.




TF Card Specification

High Speed Memory Card Memory Card
Controller AS/AK:16GB-256GB,SA:256GB-2TB
Interface SD6.1
Capacity 16GB/32GB/64GB/128GB/256GB/512GB/1TB: UHS-I
Working Voltage 2.7V-3.6V:16GB-256GB,3.3V/1.8V:512GB-2TB
Speed Level C10, U3, V30, A1, A2
Reading and Writing Speed A1:read speed 90MB/s;write speed 50MB/s(TLC)
Reading and Writing Speed A2:read speed 180MB/s;write speed 135MB/s(TLC)
File System 16GB-32GB:FAT32;64GB-2TB:exFAT
Compatibility Standards Compatible with SD(XC) supporting host devices
Operating Temperature Range 0°C-70°C
Storage Temperature Range -25°C-85°C





High read/write speed

  • Ultra High Speed (UHS) support: Modern high speed TF cards support UHS-I, UHS-II, or UHS-III standards, providing faster data transfer rates. For example, the UHS-I standard can achieve a read speed of 95MB/s and a write speed of 90MB/s, and the UHS-II and UHS-III can further increase the transfer rate for data-intensive applications that require high-speed storage and read.
  • Class 10 / U1 / U3: TF card speed classes such as Class 10 (10MB/s minimum write speed), U1 (10MB/s), and U3 (30MB/s) are used to indicate their minimum write speed. The U3 card is especially suitable for 4K video recording, high-resolution picture shooting and demanding gaming applications.



High capacity storage

  • Large storage capacity: High-speed TF cards are currently capable of providing storage capacity from 16GB to 1TB and beyond. With the development of technology, the larger and larger storage capacity enables TF cards to store more HD media, applications, data files, etc.



Durability and stability

  • Impact and high temperature resistance: Many high-speed TF cards are designed with impact resistance, water resistance and high temperature resistance, which are suitable for high-risk environments such as mobile devices and car recorders.
  • Durable write: Some high speed TF cards adopt a specific write protection technology, such as Wear Leveling Wear, which guarantees uniform wear of the storage unit inside the card over a long period of use and avoids early failure.
